CAT Hydraulic Excavator 395

More production and durability with less maintenance are what the 395 Next Generation Excavator will bring to your business.

Compare

Get a Quote

Specifications

Overview

More production and durability with less maintenance are what the 395 Next Generation Excavator will bring to your business.

Engine

Net Power - ISO 9249

404 kW

Engine Model

Cat C18

Engine Power - ISO 14396

405 kW

Bore

145 mm

Stroke

183 mm

Displacement

18.1 l

Swing Drive

24 l

Ground Clearance

830 mm

Hydraulic System

Main System - Maximum Flow - Implement

1064 l/min

Maximum Pressure - Equipment

37000 kPa

Maximum Pressure - Equipment - Lift Mode

38000 kPa

Maximum Pressure - Travel

35000 kPa

Maximum Pressure - Swing

31000 kPa

Swing

Swing Speed

6.3 r/min

Swing Mechanism

Maximum Swing Torque

362 kN·m

Weights

Operating Weight

94100 kg

Service Refill Capacities

Fuel Tank Capacity

1220 gal (

Cooling System

71 l

Engine Oil

67 l

Final Drive - Each

20 l

Hydraulic System - Including Tank

740 l

Hydraulic Tank

372 l

Shipping Length

13980 mm

Tail Swing Radius

4840 mm

Counterweight Clearance

1640 mm

Track Length

20.1 ft

Maximum Reach at Ground Level

12260 mm

Maximum Cutting Height

12370 mm

Maximum Loading Height

7960 mm

Minimum Loading Height

3660 mm

Maximum Vertical Wall Digging Depth

4580 mm

Dimensions

Boom

Mass 7.25 m (23'9")

Stick

Mass 2.92 m (9'7")

Bucket

SDV 6.5 m3 (8.5 yd3)

Shipping Height - Top of Cab

3670 mm

Handrail Height

3750 mm

Track Length to Center of Rollers

5120 mm

Transport Width

3690 mm

Boom

Mass 7.25 m (23'9")

Stick

Mass 2.92 m (9'7")

Bucket

SDV 6.5 m3 (8.5 yd3)

Undercarriage

Track Gauge

3510 mm

Turning Circle

Note

Track gauge undercarriage extended with 650 mm (26") shoes; transport width undercarriage retracted with 650 mm (26") shoes and no steps

Ripper

Maximum Digging Depth

7190 mm

Working Ranges & Forces

Maximum Depth Cut for 2440 mm (8 ft) Level Bottom

7050 mm

Bucket Digging Force - ISO

497 kN

Stick Digging Force - ISO

394 kN
